SurveyCAD Pro is a survey automation platform built for field-to-office workflows. It helps survey teams import field data, organise point codes, draft CAD linework, build surfaces and contours, create alignments and profiles, calculate quantities, and export client-ready deliverables.
SurveyCAD Pro is designed to bring survey processing, CAD drafting, surface modelling and deliverable production into a single, structured workflow — so teams can move from raw points to issued drawings with fewer manual steps.
Bring in field data from CSV, TXT and PENZD point files.
Apply code libraries, symbols and labels automatically.
Build linework, boundaries and detail in a CAD environment.
Create triangulated terrain models from survey points.
Major and minor contours with labelling and spot levels.
Import elevation rasters and georeferenced background data.
Handle large terrain datasets with level-of-detail display.
Road, rail and utility alignments with longitudinal profiles.
Section generation and cut/fill volume calculation.
PDF, DXF, CSV, GeoJSON and structured reports.
Validate levels, duplicates and linework before issue.
A0–A4 sheet layouts with scale and text control.
SurveyCAD Pro is organised into focused engines. Each engine handles one stage of the survey workflow and is designed to pass clean data to the next.
Set standards before any data is imported
Import, organise and validate field data
Familiar drafting tools for survey teams
Turn points into terrain models
Large elevation datasets, handled smoothly
Design centrelines and ground profiles
Compare surfaces and measure volumes
Prepare client-ready output
Quality checks before submission
A clear, repeatable path that helps teams keep projects consistent from the first point to the issued deliverable.
Start a new project from a standard template.
Lock in the framework before data is imported.
Bring all source data into one environment.
Symbols and labels assigned automatically.
Build detail, boundaries and feature lines.
Generate the terrain model and contour set.
Define centrelines and extract ground profiles.
Compare surfaces and calculate cut and fill.
Arrange drawings on A0–A4 sheets with title blocks.
Issue a complete, client-ready project package.
SurveyCAD Pro is designed around the day-to-day tasks of survey, mapping and engineering teams.
Detail surveys, surfaces and contour drawings.
Boundary, control and plot mapping deliverables.
Underground and surface utility records in CAD/GIS.
Alignments, profiles and corridor cross sections.
Seabed surfaces and depth-based deliverables.
Setting-out coordinates and as-built control.
Cut and fill volumes for earthworks and platforms.
Clean DXF, PDF and GeoJSON outputs for clients.
SurveyCAD Pro is designed to work with common survey, CAD and GIS formats so it fits into existing project pipelines. Supported formats, limits and export behaviour are confirmed during the demonstration.
Request a guided demonstration and we can walk your team through a field-to-finish workflow on a sample project — from point import to issued drawings.
